- – Outstanding accuracy, stability and durability
- – Upgradeable to five gas (NOx option)
- – Stand-by for extended pump life and low power consumption
- – Automatic adjustment of Warm-up time – 2 ~ 8 minutes
- – RS232 PC-Link kit (software & cables)
- – Elegant appearance
- – Portable (compact size, light weight)
- – Spare parts kit supplied as standard
- – 5 Stage filtration system for bench protection
- – Compatible with Dyno applications
- – Leak check function to check hose and probe integrity
- – Hold function to pause measurement
- – Official Emission Testing Software
- – Residual HC test
- – Fuel type selection Petrol, LPG, CNG and Alcohol
- – Stainless steel probe for extended life
- – Built in Printer
| NGA-6000 | |||||||
|---|---|---|---|---|---|---|---|
| Measuring item | CO, HC, CO2, λ (air surplus rate), AFR, NOx (optional) | ||||||
| Measuring Method | CO, HC, CO2 : NDIR Method | ||||||
| O2, NOx : Electrochemical Cell | |||||||
| Measurements | CO | HC | CO2 | O2 | LAMBDA(λ) | AFR | NOx |
| Measuring Range | 0.00~9.99% | 0~9,999 or 20,000ppm |
0.0~20.0% | 0.00~20.0% | 0~2.000 | 0.0~99.0 | 0~5,000ppm |
| Resolution | 0.01% | 1ppm | 0.10% | 0.01% | 0.001 | 0.1 | 1 ppm |
| Display | 4 Digit 7Segment LED |
4 or 5 Digit 7Segment LED |
4 Digit 7Segment LED |
4 Digit 7Segment LED |
4 Digit 7Segment LED |
4 Digit 7Segment LED |
4 Digit 7Segment LED |
| Response Time | Within 10 seconds (more than 90%) | ||||||
| Repeatability | Less than ± 2 % FS | Power | AC 110V only or AC 220V only ± 10 %, 60Hz | ||||
| Warming | About 2 ~ 8 L/min | Power Consumption | About 50 W | ||||
| Pump Flow Rate | 4 ~ 6 L/min | Operating Temperature | 0℃ ~ 40℃ | ||||
| Dimensions | 420(W) x 298(D) x 180(H) mm | Weight | About 6.9㎏ | ||||
| Basic Accessories | Probe, Sample Hose, Spare Fuse, Leak Test Cap, Spare Filter, Operators Manual, Power cord, Ground Cable, Calibration Controller Nipple, Calibration Connecting Hose, RS232 Cable, Printer, Printer Paper, PC program. | ||||||
