AUTO-i 300

  • product01_tab1_4
  • product01_tab1_5
  • product01_tab1_6
  • product01_tab1_7
  • product01_tab1_8
  • product01_tab1_9
  • product02_tab1_1
  • product02_tab1_1
  • product02_tab1_2
  • product02_tab1_3
AUTO-i 300
Operating SystemWindows XP, Windows VISTA, Windows7, Windows8
Diagnostic ProcessorCortex M3 120MHz
ConnectivityBluetooth V.2.0
USB : 2.0
Power and BatteryLi-ion Polymer 2100mAh 1cell Battery, Charging via 12V AC/DC Power Supply
Power Consumption2.4W
Dimensions (WxWxD)130mm (5.11")x 195mm (7.68")x 50mm (1.97")
Weight680 g (1.50lb)
Operating Voltage7.5~36V
Operating Temperature 0 to 45℃ (32 to 113℉)
Storage Temperature-20 to 70℃ (-4 to 158℉)
ProtocolsISO 9142-2, ISO 14230-2, ISO 15765-4, SAE-J1850, SAE-J1850 PWM
CAN ISO 11898, Highspeed, Middlespeed, Lowspeed and Singlewire CAN
K/L-Line High Speed Serial, Flashing Code, Ethernet Protocol
Byte Protocol, Honda Diag-H Protocol, KWPT 1281, TP2.0, TP1.6, J2610(Chrysler SCI)
Basic Kit
PART NO
PART NAME
AY-ELPT-A300AUTO-i 300 MAIN BODY 구성품확대
CB-CYAT-0001DLC MAIN CABLE (16P) 구성품확대
CB-CYVG-0006CIGAR LIGHTER POWER CABLE 구성품확대
CB-CNHC-0004BATTERY EXTENTION CABLE 구성품확대
CB-AYTP-0001AC/DC POWER ADAPTOR (3.5A 40W) 구성품확대
CB-CYTP-0004AC ELECTRIC POWER CORD 구성품확대
CB-CYAU-001AUSB CABLE(A-B) 구성품확대
LA-DQAU-A001OPERATION MANUAL CD 구성품확대
PK-BGTT-0005CARRYING CASE 구성품확대
FE-MUDE-0047BLUE TOOTH DONGLE SET (INCLUDED) 구성품확대
Asian Kit
PART NO
PART NAME
CB-AYHC-0018KIA ADAPTOR 20P (BLUE) 구성품확대
CB-AYVG-0003KIA,MAZDA ADAPTOR (6+1P) 구성품확대
CB-AYVG-0005DAEWOO,GM ADAPTOR (12P) 구성품확대
CB-AYVG-0006SSANGYONG ADAPTOR (14P) 구성품확대
CB-AYVG-0007SSANGYONG ADAPTOR (20P) 구성품확대
CB-AYVG-0008SAMSUNG / NISSAN ADAPTOR (14P) 구성품확대
CB-CYHC-0018HYUNDAI,MITSUBISHI CABLE (12P) 구성품확대
CB-AYVG-0002TOYOTA, LEXUS ADAPTOR (17P"C") 구성품확대
CB-AYVG-0001TOYOTA, LEXUS ADAPTOR (17P"R") 구성품확대
CB-AYVG-0012HONDA ADAPTOR (5P) 구성품확대
CB-AYVG-0009HONDA ADAPTOR (3P) 구성품확대
CB-AYVG-0010MAZDA "C" ADAPTOR (17P) 구성품확대
CB-AYVG-0011SUBARU ADAPTOR (16P-9P) 구성품확대
CB-CYVG-0007MITSUBISHI CABLE (12P+16P) 구성품확대
EUR. / AUS. / USA KIT
PART NO
PART NAME
CB-CYHC-0022AUDI / VW CABLE (2+2P) 구성품확대
CB-AYVG-0013BMW ADAPTOR (20P) 구성품확대
CB-AYHC-0016BENZ 38PIN BOARD 구성품확대
CB-CYHC-0023BENZ CABLE (3LINER) 구성품확대
CB-AYVG-0014OPEL ADAPTOR (10P) 구성품확대
CA-PSA1-0002PSA CABLE (2PIN) 구성품확대
CN-T005-AM06FIAT ADAPTOR (3P) 구성품확대
CB-CYHC-0031FORD CABLE (20P) 구성품확대
CB-CYVG-0009HOLDEN ADAPTOR (6P) 구성품확대
